Kitagawa P-41R Compressed Breathing Air Analysis Kit
Occupational Safety Gas Measurement, Sampling, and Analysis Instruments
Komyo Kitagawa P-41R
High-specification air quality sampling and analysis kit for measuring impurities in compressed breathing air cylinders and at the outlets of air-charging compressors. Impurities inside compressed air cylinders affect human health during breathing. The P-41R allows you to easily analyse impurities in compressed air by delivering air from the gas cylinder to the detector tube via a dedicated pressure-reduction valve.
Technical Specifications
Show Technical Details
| Substances to be Measured | Tube No. | Measurement Range | Sampling Time (min) | Original Colour | Discolouration | Shelf Life (Years) | Tube Quantity (Box) |
|---|---|---|---|---|---|---|---|
| Carbon monoxide (CO) | 600SP | 2.5–5 ppm / 5–100 ppm | 4 min (2.5–5 ppm); 2 min (5–100 ppm) | Yellow | Dark Brown | 2 | 10 |
| Carbon dioxide (CO₂) | 601SP | 100–3,000 ppm | 2 | Purplish Blue | Pale Pink | 2 | 10 |
| Oil Mist (Oil Mist) | 602SP | 0.3 ~ 5mg/m3 | 25 | Yellow | Pale Blue | 2 | 10 |
| Water Vapour (H2O) | 603SPA | 20 ~ 160mg/m3 | 1 | Yellow | Yellowish Green or Blue | 3 | 10 |
| Oxygen (O2) | 604SP | 2 ~ 24% | 1 | White | Brown | 2 | 10 |
Gas Measurement and Standard Approach
The P-41R is designed for impurity measurement by delivering compressed breathing air from a gas cylinder or compressor discharge to detector tubes in a controlled manner via a dedicated regulator. The manufacturer's current P-41R table lists tubes 600SP for CO, 601SP for CO₂, 602SP for oil mist, 603SPA/603SP2 for water vapour and 604SP for O₂. The acceptance criteria limits to be applied must be independently determined in accordance with the relevant breathing air standard, institutional procedure or application specification.
Sectors
Alternative Products
You can examine product details and technical specifications by selecting an alternative suited to your requirements.
Brand and support in Turkey: Komyo Kitagawa Turkey — NOVEL Ltd., Sole Authorised Distributor of Komyo Kitagawa Turkey. You may review the brand page for brand product groups, related products and technical support information.
Notice: The technical information, product specifications and images on this page are based on manufacturer publications. The manufacturer may change specifications without notice. For current specifications or assistance in selecting a suitable product for your application, please contact NOVEL at info@novel.com.tr .
