NOVEL · Product and System Solutions
Gas Detectors and Industrial Measurement Instruments
The Shinyei OMX family consists of portable instruments that quantitatively monitor odour or TVOC trends using dual semiconductor sensors and an integral sampling pump. The OMX-SRM, OMX-ADM, or OMX-TDM model is selected according to the indication required by your application.
Comparative evaluation of odour levels supports the assessment of cleaning, ventilation, and deodorisation processes.
Request a Quote from NOVEL ↗OMX-SRM
Quantitatively tracks variations in odour intensity across manufacturing areas, waste processing facilities, and similar environments. The odour classification indicator assists in comparative sampling.
View Technical Specifications ↓OMX-ADM
Assists in assessing deodorisation performance in hospitals, care facilities, and similar environments. Designed for monitoring fluctuations in pungent odours such as ammonia.
View Technical Specifications ↓OMX-TDM
Monitors total volatile organic compound trends in indoor air quality studies. Values are presented as toluene equivalents; this is not a selective analytical method identifying individual chemical compounds.
View Technical Specifications ↓Readings depend on the model. The instrument does not identify individual constituent compounds of an odour. The manufacturer states that this product does not carry CE marking; project requirements should be evaluated during model selection.
| Odour strength level | 0,0–999 |
|---|---|
| Odour classification indicator | 0–90 |
| Measurement method | Two semiconductor gas sensors |
| Sampling | Continuous sampling with built-in pump |
| Power supply | 4 × AA alkaline batteries or AC adapter; approx. 7 hours continuous use with alkaline batteries |
| Data memory | 32,732 data points; up to 511 files |
| Operating conditions | 0…40 °C, non-condensing environment |
| Dimensions | 74 × 167.5 × 35 mm |
| Weight | Approx. 250 g; excluding batteries |
| Odour strength level | 0–999 |
|---|---|
| Odour intensity indicator | 2,5–5,0 |
| Measurement method | Two semiconductor gas sensors |
| Sampling | Continuous sampling with built-in pump |
| Power supply | 4 × AA alkaline batteries or AC adapter; approx. 7 hours continuous use with alkaline batteries |
| Data memory | 32,732 data points; up to 511 files |
| Operating conditions | 0…40 °C, non-condensing environment |
| Dimensions | 74 × 167.5 × 35 mm |
| Weight | Approx. 250 g; excluding batteries |
| TVOC indication | 0–9,999 µg/m³; toluene equivalent |
|---|---|
| Measurement method | Two semiconductor gas sensors |
| Sampling | Continuous sampling with built-in pump |
| Power supply | 4 × AA alkaline batteries or AC adapter; approx. 7 hours continuous use with alkaline batteries |
| Data memory | 32,732 data points; up to 511 files |
| Operating conditions | 0…40 °C, non-condensing environment |
| Dimensions | 74 × 167.5 × 35 mm |
| Weight | Approx. 250 g; excluding batteries |
Compare the intended use of the three models with the short introductory videos on the NOVEL Ltd. YouTube channel.
Technical resource: Official Shinyei OMX product information ↗
You can examine product details and technical specifications by selecting an alternative suited to your requirements.
Notice: The technical information, product specifications and images on this page are based on manufacturer publications. The manufacturer may change specifications without notice. For current specifications or assistance in selecting a suitable product for your application, please contact NOVEL at info@novel.com.tr .
